600KW斗山大宇系列
斗山能提供10種常用和非常用的柴油發電機組的發動機,這10種型號的柴油發動機均滿足美國EPA排氣標準,其功率范圍從35KW-649KW的發動機。在大氣溫度為40℃、高度1000M時能維持輸出功率。熱帶地區用冷卻系統,保證輸出功率0-2%。低排放、低噪音。以最新的新技術噴射和空氣壓縮系統帶來低內耗而保障優秀的燃燒性能和燃油消耗低。所有的發動機都符合美國EPA和CARB TIER排氣標準。耐久性及低噪音,簡便、迅速及經濟安裝的設計思想,提供平穩、無震動而噪音低的均衡設計。由于采用了活塞冷卻系統,從而非常容易控制汽缸和燃燒室的工作溫度。 Doosan provides engines for 10 common and very useful diesel generators, all of which meet U.S. EPA exhaust standards and have power ranges from 35kw-649kw engines. In the atmospheric temperature of 40 ℃, altitude 1000 m can maintain the output power. Cooling systems are used in the tropics to ensure output power of 0-2%. Low emission, low noise. With the latest technology jet and air compression system to bring low internal consumption and ensure excellent combustion performance and low fuel consumption. All engines meet the U.S. EPA and CARB TIER exhaust standards. Durability and low noise, simple, quick and economical installation design ideas to provide a smooth, vibration free and low noise balanced design. The piston cooling system makes it easy to control the operating temperature of the cylinder and combustion chamber. |
機組型號 | 輸出功率KW | 輸出功率KVA | 電流A | 柴油機型號 | 缸數 | 缸徑*行程mm | 潤滑油容量L | 油耗g/kw.g | 機組外形尺寸L×W×H | 機組重量kg |
FM50GF | 50 | 62.5 | 90 | DB58 | 6 | 102*118 | 15 | 215 | 2000*730*1150 | 900 |
FM64GF | 64 | 80 | 115.2 | D1146 | 6 | 111*139 | 18 | 222 | 2200*800*1500 | 1100 |
FM75GF | 75 | 93.75 | 135 | D1146 | 6 | 111*139 | 18 | 222 | 2200*800*1500 | 1100 |
FM100GF | 100 | 125 | 180 | D1146T | 6 | 111*139 | 18 | 200 | 2300*800*1500 | 1500 |
FM120GF | 120 | 150 | 216 | DP086TA | 6 | 111*139 | 18 | 201 | 2300*800*1500 | 1600 |
FM132GF | 132 | 165 | 237.6 | DP086TA | 6 | 111*139 | 18 | 201 | 2300*800*1500 | 1600 |
FM150GF | 150 | 187.5 | 270 | P086TI-1 | 6 | 111*139 | 18 | 207 | 2550*1000*1500 | 1750 |
FM180GF | 180 | 225 | 324 | P086TI | 6 | 111*139 | 18 | 202 | 2600*1000*1500 | 1800 |
FM200GF | 200 | 250 | 360 | DP086LA | 6 | 111*139 | 20 | 203 | 2700*1000*1500 | 1800 |
FM220GF | 220 | 275 | 396 | P126TI | 6 | 123*155 | 20 | 205 | 2900*1050*1650 | 2400 |
FM240GF | 240 | 300 | 432 | P126TI | 6 | 123*155 | 20 | 205 | 2900*1050*1650 | 2400 |
FM260GF | 260 | 325 | 468 | P126TI-Ⅱ | 6 | 123*155 | 25 | 202 | 3000*1050*1650 | 2600 |
FM300GF | 300 | 375 | 540 | P158LE-1 | 8 | 128*142 | 33 | 232 | 3100*1400*1850 | 2700 |
FM320GF | 320 | 400 | 576 | P158LE-1 | 8 | 128*142 | 33 | 232 | 3100*1400*1850 | 2700 |
FM350GF | 350 | 437.5 | 630 | P158LE | 8 | 128*142 | 33 | 209 | 3100*1400*1850 | 2800 |
FM400GF | 400 | 500 | 720 | DP158LCF | 8 | 128*142 | 35 | 210 | 3120*1400*1850 | 3000 |
FM440GF | 440 | 550 | 792 | DP158LDF | 8 | 128*142 | 40 | 205 | 3300*1400*1850 | 3300 |
FM500GF | 500 | 625 | 900 | DP180LAF | 10 | 128*142 | 45 | 200 | 3400*1400*1850 | 3500 |
FM550GF | 550 | 687.5 | 990 | DP180LBF | 10 | 128*142 | 45 | 207 | 3400*1400*1850 | 3700 |
FM600GF | 600 | 750 | 1080 | DP222LBF | 12 | 128*142 | 45 | 210 | 3500*1400*1850 | 4000 |
FM650GF | 650 | 812.5 | 1170 | DP222LCF | 12 | 128*142 | 50 | 207 | 3600*1400*1850 | 4500 |
1.以上技術參數轉速為1500RPM,頻率50HZ,額定電壓400/230V,功率因數0.8,接線方式為三相四線。 2.發電機可以根據客戶需求,選用上海斯坦福、上海馬拉松、無錫斯坦福等知名品牌。 3.60HZ發電機組可以根據客戶的特殊需要定制。 4.本參數表僅供參考,如有更改恕不另行通知。 | ||||||||||
標準配置 Standard equipment: 發動機 diesel engine 發電機 alternator 散熱器 water cooled radiator 工業消音器 、波紋管 industrial silencer and flexible exhaust hose 啟動免維護蓄電池及蓄電池 電池連接線 maintenance-free lead-acid starting batteries and battery connect wires 輸出斷路器 output circuit breaker 智能控制屏 digital control panel 鋼式底架 steel base frame | ||||||||||
可選配置 Optional equipment 低噪音靜音機箱 Low noise silent case 四輪移動拖車電站 Four-wheel mobile trailer power station 自啟動、自轉換 開關柜 Self - start, self - conversion switch cabinet 自動并機控制系統 automatic parallel operation control system 電熱式水套加熱器 electrothermal water jacket heater |
